Prolink PRO701SFC line Interactive UPS

2 Years Warranty

SPECIFICATIONS

GENERAL

Capacity	650VA
Dimension (mm)	286 x 96 x 138 (D x W x H)
Weight (kg)	4.3

INPUT

Voltage Range	162 ~ 290VAC (Single boost) 140 ~ 300VAC (Double boost)
Frequency	50Hz/60Hz (Auto-sensing)
Phase	Single + GND

OUTPUT

Voltage Range	220-240VAC
Battery Mode	220-240VAC
Frequency	50Hz ±1% (Battery mode)
Waveform	Simulated sine wave (Battery mode) Sine wave (AC mode)
Transfer Time	2ms typical

BATTERY

Type	12V/8.2AH x 1
Backup Time	8 - 20 mins depending on load
Recharge Time	2-4 hours recover to 90% capacity

INTERFACE & INDICATORS

Interface	RS232, USB port, RJ45/RJ11 (Optional)
Display	LED/LCD Optional
Alarm	Batt. Mode, low battery, overload, fault, etc.

PROTECTION/MONITORING

Short Circuit Protection	Yes (Line mode & battery mode)
Surge Protection	Yes
Alarm	Audible & Visual
Overload Protection	Line mode : 100 - 120% 1 min change to fault mode >120% change to fault mode immediately Battery mode : 100 - 120% 1 min change to fault mode >120% change to fault mode immediately
Intelligent Battery	Prevent overcharging of battery
Management	Protect battery and prolong battery life
